แท่นชั่งรถบรรทุก 50ตัน
เครื่องชั่งรถบรรทุก เครื่องชั่งรถสิบล้อ50t
รับติดตั้งเครื่องชั่งน้ำหนักรถบรรทุก
รับซ่อมตาชั่งรถทุกชนิด
ขนาดแท่น3x8 เมตร,3x9 เมตร
พิกัดชั่งสูงสุด50ตัน
โครงสร้างเหล็ก Mainbeam:400,500mm.
แบบพื้นแท่นชั่งหน้าปูน
แบบพื้นแท่นชั่งหน้าเหล็ก
สนใจติดต่อสอบถาม/ขอเสนอราคา:
โทร. 02-0401497 แฟกซ์: 02-0401498
สายด่วนรับปรึกษา/รับซ่อม: 08-4422-3023,
08-6308-0095
เพียงลูกค้ามีพื้นคอนกรีตรอเราสามารถติดตั้งแท่นชั่ง ทำทางขึ้นง/ลง
และเซ็ตระบบให้พร้อมใช้พร้อมตรวจรับรองฯ
พร้อมงานถักเหล็ก/ผูกเหล็กสองชั้น
ทั้งในแท่นชั่งและทางขึ้น/ลง ปูนคอนกรีตที่ใช้ทนแรงอัดสูง 280/320Ksc.
ปรึกษางานติดตั้งเครื่องชั่งรถพร้อมใช้งานราคาถูก ติดต่อเราได้08-6308-0095
Specifications: Type:KT38-500
1.Capacity: 50T SIZE: 3×8M
2.Structure: WF beams and HB beams and congrete deck
2.Technical parameters of the system:
|
1 |
quantitative structure |
2Mainbeam, 5Crossbeam |
|
2 |
max weigh |
50(T) |
|
3 |
maximum display division |
1/100,000 |
|
4 |
Index value |
10KG |
|
5 |
Sensor capacity |
KOSUMO series,40t |
|
6 |
The degree of accuracy |
OIML Ⅲ |
|
7 |
Work environment |
temperature:-20 degree—±70 degree |
|
8 |
power supply |
220VAC (+10%,-15%)50HZ±2% |
4.The main structure parts
1,material:Main beam Wide Flange 500x200 mm,Cross H-baem 200x200mm.
2,Painting process: two rust red paint... The two top coat
3,unit number:6,5
4.Congrete deck: 320 ksc.
5.sensor type:ZSF-40t,number:8
|
name |
unit |
Parameters |
|
|
Rated capacity |
T |
40x4 |
|
|
Rated output |
Mv/v |
2±0.002 |
|
|
Don't repeat |
%Fs |
0.02 |
0.03 |
|
lag |
%Fs |
0.02 |
0.03 |
|
Nonlinear |
%Fs |
0.02 |
0.03 |
|
Zero output |
%Fs |
1 |
|
|
Temperature compensation range |
℃ |
-10-55 |
|
|
Using the temperature coefficient |
℃ |
-20-70 |
|
|
Output temperature coefficient |
%Fs |
0.0020 |
|
|
The zero temperature coefficient |
%Fs |
0.0020 |
|
|
The input impedance |
Ω |
750±4 |
|
|
Output impedance |
Ω |
700±1 |
|
|
Recommend the excitation voltage |
V |
6-15(DC/AC) |
|
|
Maximum voltage |
V |
20(DC/AC) |
|
|
Insulation resistance |
MΩ |
≥5000 |
|
|
Safety overload |
%Fs |
150 |
|
|
Permission overload |
%Fs |
300 |
|
|
The safe side load |
%Fs |
300 |
|
|
Side load restraint ratio |
|
500:1 |
|
|
Protection grade |
|
IP68 |
|
6.meter
1,types:MG-911 or PM-02
2,number:1
3,the main function
(1)The 20 keypad operation(PM-02) or keyboard (MG-911)
(2)a six bit seven fluorescent display [VFD] or LCD with back light (MG-911)
(3)the keyboard and buttons zero functions;
(4)simple span and zero
(5)the optional 2mv/V or 3MV /V sensor input or digital loadcell
(6)the excitation voltage is 7-10VDC, it can drive 8 / 350ohm sensor;
(7)automatic zero tracking function (AXM); automatic zero capture function (AZC)
(8)digital filter
(9)overload the display;
(10)the period of time, the function of;
(12)the Meter port RS-232x2 , for display and computer.
(13)the Meter port RS-232x1 , for display and parallel port x1 for direct printer.
(15)100 a number of storage, 900 weighing records storage or above
7.Accessories detail :
|
no |
name |
type |
number |
|
1 |
The main structure |
3M×18M |
2 |
|
2 |
sensors |
Kosumo series |
4 |
|
3 |
printer |
Epson-LQ |
1 |
|
4 |
cable |
The four core double shielded cable |
1 |
|
5 |
terminal box |
AI-411 satainless |
1 |
|
6 |
foundation works |
customer made |
|
|
7 |
installation charge |
customer is responsible |
|
โครงสร้างแท่นชั่งรับน้ำหนักได้จริง ไม่ลดสเป็คเหล็ก/ปูน
อุปกรณ์ชั่งได้มาตรฐาน พร้อมระบบป้องกันทางเทคนิค เพื่อความเสถียรและมีประสิทธิภาพ
เรารับประกันงาน เครื่องเสียเข้าไปแก้ไขภายใน24-48ชั่วโมง
เพราะเราเข้าใจ ว่างานชั่งสำคัญกับธุรกิจของลูกค้าเสมอ
สนใจติดต่อ 02-0401497,084422-3023
Technical parameter:
Power source: 220V AC(+10%,-15%)50Hz±2%
Work environment: -30°C—70°C
Work environment of sensors: -1°C—55°C
Work environment of digital terminal: 1°C—40°C
Relative humidity:20%--90% RH
Weight accuracy: Base on DIT thailand.
---------------------------------------------------------------------------------------------------------------------------------------------
เครื่องชั่งรถบรรทุก50ตัน ราคาถูก
Specifications: Type:KT38-400
1.Capacity: 50T SIZE: 3×8M
2.Structure: WF beams and HB beams and congrete deck
2.Technical parameters of the system:
|
1 |
quantitative structure |
2Mainbeam, 5Crossbeam |
|
2 |
max weigh |
50(T) |
|
3 |
maximum display division |
1/100,000 |
|
4 |
Index value |
10KG |
|
5 |
Sensor capacity |
QS-30t |
|
6 |
The degree of accuracy |
OIML Ⅲ |
|
7 |
Work environment |
temperature:-20 degree—±70 degree |
|
8 |
power supply |
220VAC (+10%,-15%)50HZ±2% |
4.The main structure parts
1,material:Main beam Wide Flange 400x200 mm,Cross H-baem 200x200mm.
2,Painting process: two rust red paint... The two top coat
3,unit number:2,5
4.Congrete deck: 280 ksc.
5.sensor type:ZSF-40t,number:4
|
name |
unit |
Parameters |
|
|
Rated capacity |
T |
40x4 |
|
|
Rated output |
Mv/v |
2±0.002 |
|
|
Don't repeat |
%Fs |
0.02 |
0.03 |
|
lag |
%Fs |
0.02 |
0.03 |
|
Nonlinear |
%Fs |
0.02 |
0.03 |
|
Zero output |
%Fs |
1 |
|
|
Temperature compensation range |
℃ |
-10-55 |
|
|
Using the temperature coefficient |
℃ |
-20-70 |
|
|
Output temperature coefficient |
%Fs |
0.0020 |
|
|
The zero temperature coefficient |
%Fs |
0.0020 |
|
|
The input impedance |
Ω |
750±4 |
|
|
Output impedance |
Ω |
700±1 |
|
|
Recommend the excitation voltage |
V |
6-15(DC/AC) |
|
|
Maximum voltage |
V |
20(DC/AC) |
|
|
Insulation resistance |
MΩ |
≥5000 |
|
|
Safety overload |
%Fs |
150 |
|
|
Permission overload |
%Fs |
300 |
|
|
The safe side load |
%Fs |
300 |
|
|
Side load restraint ratio |
|
500:1 |
|
|
Protection grade |
|
IP67 |
|
6.meter
1,types:MG-911 or PM-02
2,number:1
3,the main function
(1)The 20 keypad operation(PM-02) or keyboard (MG-911)
(2)a six bit seven fluorescent display [VFD] or LCD with back light (MG-911)
(3)the keyboard and buttons zero functions;
(4)simple span and zero
(5)the optional 2mv/V or 3MV /V sensor input or digital loadcell
(6)the excitation voltage is 7-10VDC, it can drive 8 / 350ohm sensor;
(7)automatic zero tracking function (AXM); automatic zero capture function (AZC)
(8)digital filter
(9)overload the display;
(10)the period of time, the function of;
(12)the Meter port RS-232x2 , for display and computer.
(13)the Meter port RS-232x1 , for display and parallel port x1 for direct printer.
(15)100 a number of storage, 900 weighing records storage or above
7.Accessories detail :
|
no |
name |
type |
number |
|
1 |
The main structure |
3M×8M |
2 |
|
2 |
sensors |
KELI QS-30t |
4 |
|
3 |
printer |
Epson-LQ |
1 |
|
4 |
cable |
The four core double shielded cable |
1 |
|
5 |
terminal box |
AI-411 satainless |
1 |
|
6 |
foundation works |
customer made |
|
|
7 |
installation charge |
customer is responsible |
|
โครงสร้าง 300x200
Specifications: Type:KT38-3006
1.Capacity: 50T SIZE: 3×8M
2.Structure: WF beams and HB beams and congrete deck
2.Technical parameters of the system:
|
1 |
quantitative structure |
4Mainbeam, 6Crossbeam |
|
2 |
max weigh |
50(T) |
|
3 |
maximum display division |
1/100,000 |
|
4 |
Index value |
10KG |
|
5 |
Sensor capacity |
KELI QS-30t |
|
6 |
The degree of accuracy |
OIML Ⅲ |
|
7 |
Work environment |
temperature:-20 degree—±70 degree |
|
8 |
power supply |
220VAC (+10%,-15%)50HZ±2% |
4.The main structure parts
1,material:Main beam Wide Flange 300x200 mm,Cross H-baem 200x200mm.
2,Painting process: two rust red paint... The two top coat
3,unit number:4,6
4.Congrete deck: 320 ksc.
5.sensor type:ZSF-40t,number:8
|
name |
unit |
Parameters |
|
|
Rated capacity |
T |
30x6 |
|
|
Rated output |
Mv/v |
2±0.002 |
|
|
Don't repeat |
%Fs |
0.02 |
0.03 |
|
lag |
%Fs |
0.02 |
0.03 |
|
Nonlinear |
%Fs |
0.02 |
0.03 |
|
Zero output |
%Fs |
1 |
|
|
Temperature compensation range |
℃ |
-10-55 |
|
|
Using the temperature coefficient |
℃ |
-20-70 |
|
|
Output temperature coefficient |
%Fs |
0.0020 |
|
|
The zero temperature coefficient |
%Fs |
0.0020 |
|
|
The input impedance |
Ω |
750±4 |
|
|
Output impedance |
Ω |
700±1 |
|
|
Recommend the excitation voltage |
V |
6-15(DC/AC) |
|
|
Maximum voltage |
V |
20(DC/AC) |
|
|
Insulation resistance |
MΩ |
≥5000 |
|
|
Safety overload |
%Fs |
150 |
|
|
Permission overload |
%Fs |
300 |
|
|
The safe side load |
%Fs |
300 |
|
|
Side load restraint ratio |
|
500:1 |
|
|
Protection grade |
|
IP68 |
|
6.meter
1,types:MG-911 or PM-02
2,number:1
3,the main function
(1)The 20 keypad operation(PM-02) or keyboard (MG-911)
(2)a six bit seven fluorescent display [VFD] or LCD with back light (MG-911)
(3)the keyboard and buttons zero functions;
(4)simple span and zero
(5)the optional 2mv/V or 3MV /V sensor input or digital loadcell
(6)the excitation voltage is 7-10VDC, it can drive 8 / 350ohm sensor;
(7)automatic zero tracking function (AXM); automatic zero capture function (AZC)
(8)digital filter
(9)overload the display;
(10)the period of time, the function of;
(12)the Meter port RS-232x2 , for display and computer.
(13)the Meter port RS-232x1 , for display and parallel port x1 for direct printer.
(15)100 a number of storage, 900 weighing records storage or above
7.Accessories detail :
|
no |
name |
type |
number |
|
1 |
The main structure |
3M×8M |
4 |
|
2 |
sensors |
QS-30t |
6 |
|
3 |
printer |
Epson-LQ |
1 |
|
4 |
cable |
The four core double shielded cable |
1 |
|
5 |
terminal box |
AI-411 satainless |
1 |
|
6 |
foundation works |
customer made |
|
|
7 |
installation charge |
customer is responsible |
|
